SX Series 30” Class 165 Watt LED Light Bar. This complex lens single row light bar features white LED’s arranged 90 degrees away from view to create a blackout look that also packs more LED’s in a tighter space for maximum range in a compact package. Narrow spot beam for maximum distance and visibility of over half a mile.
Great for mounting on your truck, ATV/UTV, or Side by Side along with some Pro Pod XL lights to hit all areas with maximum light. Attach almost anywhere with Jammy OffRoad multi-mount brackets that can be bolted or screwed on, even on curved surfaces like a hood or roof. Connect with simple 2-Wire setup using included DT04-2P connectors and generous 18″ lead wire.
Built for extreme durability in the harshest conditions. Max life UV protected polycarbonate affixed to aluminum housing using Jammy OffRoad’s perma-seal bonding process creates a fixture with IP69K rating that is literally hammer proof.
- Rated Power: 165 Watts
- Actual Power: 135 Watts
- Amps at 12.5 Volts: 10.8
- LED: 33x OSRAM 5-Watt
- Lumens (effective): 12,945
- Lux at 10 Meters: 1,878
- Beam Distance at 1 Lux: 1,394
- Max Beam Distance (0.25 lx): 2,789 Feet
- See dimensional chart for actual size
Click Here for help understanding power figures, beam info,and IP rating
- OSRAM LED’s and Thermally Regulated Electronics
- Included Side Mount & Adjustable Rear Mount Brackets
- Rubber (PVC) Isolating Pads for Brackets
- Low Profile Aluminum No-Whistle Housing
- Breather Vent to Prevent Moisture Buildup
- Wide 10-30 Volt Operating Range
- Top Grade Polycarbonate Lens
- Multi-Core Jacketed Lead Wire
- Stainless Steel Hardware
- IP69K Rated
